Supported Camera
| COMPONENT | SPECIFICATION |
|---|---|
| Compatible Vendor | i-PRO series Network cameras, ONVIF NVT conformant camera and encoder |
| Supported Image Format | H.265(HEVC), H.264, JPEG |
| Supported Image Resolution | •Aspect ratio [4 : 3]
3,072×2,304, 2,560×1,920, 2,048×1,536, 1,600×1,200, 1,280×960, 800×600, 640×480 •Aspect ratio [16 : 9] 3,840×2,160, 3,328×1,872, 3,072×1,728, 2,688×1,520, 2,560×1,440, 1,920×1,080, 1,280×720, 640×360 •Aspect ratio [1 : 1] 2,992×2,992, 2,816×2,816, 2,192×2,192, 2,048×2,048, 1,440×1,440, 1,280×1,280, 1,200×1,200 •Aspect ratio [9 : 16] 2,160×3,840, 1,872×3,328, 1,728×3,072, 1,520×2,688, 1,440×2,560, 1080×1920, 720×1280, 360×640 |
| Supported Audio Format | AAC-LC, G.711(for ONVIF) |
| Maximum Number of Cameras | Max. 128 (Default number of cameras : 64) |
Recording
| COMPONENT | SPECIFICATION |
|---|---|
| Recording Mode | Event, Schedule, Emergency, Pre-event recording |
| Pre-Alarm Recording | Up to 15 seconds *When the delivery speed from the network camera is less than 4 Mbps |
| Sub-Stream Recording | – |
| Scheduled Recording Mode | 16 programs, 6 time zones/day, Independent setup for each day of the week |
| Frame Rate | Up to 60 fps (Depending on the camera) |
Main Unit Functions
| COMPONENT | SPECIFICATION |
|---|---|
| Camera Control | Pan/Tilt, Zoom, Focus, Brightness, Preset position call and program (up to 256), Auto mode, Click centering, Wheel zoom, Zoom reset, Auto Back Focus, Aux, Wiper (for WV-SUD638), Active ClearSight |
| Multiscreen Mode | [Main monitor]
Control screen: 4 / 9 / 16 split screen display Wide view screen: 2 / 3 / 4 / 5 / 6 / 7 / 9 / 12 / 16 / 24 / 32 /64 split screen display, 1 screen sequence, 4 / 9 / 16 split screen sequence [Sub monitor] 1 / 4 / 9 / 16 / 32 split screen display, 1 screen sequence, 4 / 9 / 16 split screen sequence |
| Playback Control | PLAY, Rev PLAY, Pause, Stop, FF, FR, Prev Record, Next Record, Prev Image, Next Image, Go to Date, Go to Last (30 s), Time-saving playback |
| Search Mode | Search criteria : Time date, Playback by designating a timeline, Thumbnail |
| Copy | File Format : Original Format / MP4 Recorded data of selected cameras and time date range can be copied to USB storage. |
| Camera Title | Up to 16 Characters |
| Clock Display | Time : 12H/24H, Date : 5 formats |
| Digital Zoom | Live / Play : 1.25x 1.5x 1.75x, 2x, 2.5x, 3x, 3.5x 4x, 5x, 6x, 7x, 8x (only for 1-screen or 4-screen) |
| System Log | Operator access (500), Network error (100), Error (1,000), Event (1000), Operation (500) |
| System Setup Language | Setup page in English, French, Italian, Spanish, German, Portuguese, Thai, Vietnamese, Simplified Chinese, Traditional Chinese, Japanese |
| 360 Camera Dewarp | Only 1ch display mode Display : 1-Screen PTZ / 4-Screen PTZ |
| Re-Encoding | 2 clients |
| SD Memory Data Download | Images recorded in the SD card in the i-PRO series cameras can be transferred to the recorder automatically. (H.265/H.264) |
| User Registration | Up to 32 users |
| User Level | 3 Levels (Programmable) |
| Partitioning | User level – Camera (View & Control, View Only, No Access) |
| Security Method | User authentication (ID and Password), Host authentication, SSL/TLS, Data encryption (Only when using Secure communication kit) |
Web Browser
| COMPONENT | SPECIFICATION |
|---|---|
| Camera Control | Pan/Tilt, Zoom, Focus, Brightness, Preset position call and program (up to 256), Auto mode, Click centering, Wheel zoom, Zoom reset, Aux, Wiper (for WV-SUD638), Active ClearSight |
| Playback Control | PLAY, Rev PLAY, Pause, Stop, FF, FR, Prev Record, Next Record, Prev Image, Next Image, Go to Date, Go to Last |
| Search Mode | Search criteria : Time date, Event type, VMD, Camera number |
| Display Mode | 1 screen |
| Image Download | File Format : Original Format / MP4 Recorded data of selected camera and time range can be downloaded to a PC. Viewer software can be downloaded separately |
| Camera Title | Up to 16 characters |
| Clock Display | Time : 12H/24H, Date : 5 formats |
| Alarm Control | Reset |
| Digital Zoom | – |
| GUI Language | Setup page in English, French, German, Italian, Spanish, Portuguese, Thai, Vietnamese, Simplified Chinese, Traditional Chinese, Japanese |
| Required PC | CPU : Intel® Core™ i7-860 or faster, RAM : 4 GB or more, VRAM : 128 MB or more (Min. 64 MB), Microsoft® DirectX® 9.0c or later |
Alarm/Event
| COMPONENT | SPECIFICATION |
|---|---|
| Alarm Source | 32x Terminal inputs, 128x Camera alarms (TCP alarm notification), 128x Command alarms |
| Event Mode | Off / On(Recording & alarm action, Recording only) |
| Alarm Action | Alarm recording, E-mail notification, Alarm message, Camera positioning, Terminal output, TCP alarm notification, HTTP alarm notification, Buzzer, Indicator |
| Alarm Control | Reset |
| Event Log | Up to 1000 |
Input/Output
| COMPONENT | SPECIFICATION |
|---|---|
| Monitor (HDMI) Connector | [Main monitor]
HDMI 4K UHD(3840x2160p)/30Hz, 4K UHD(3840x2160p)/25Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, [Sub monitor] HDMI 4K UHD(3840x2160p)/30Hz, 4K UHD(3840x2160p)/25Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, |
| Audio Output Connector | N/A |
| Alarm IO | Alarm in: 32 Alarm out: 4 |
| Control IO | Network error output Alarm reset input Emergency recording input Power failure detection input External recording mode switching input HDD error output Camera error output Device error output Recorder error output Power failure processing completion output +5V output (200mA) Spare input/output x5 |
| Mouse Connection Port | x1 USB2.0 conformant port in front side, DC5V/500mA (with over current limitation function) |
| Camera/PC Network Port | 2x 10BASE-T / 100BASE-TX / 1000BASE-T (RJ45) |
| Maintenance Network Port | 1x 10BASE-T / 100BASE-TX |
| USB Storage | Front: USB 3.0/USB 2.0 stick, USB 3.0/USB 2.0 HDD (self-powered device only) Rear: USB 3.0/USB 2.0 stick, USB 3.0/USB 2.0 HDD (self-powered device only), USB 3.0/USB 2.0 SSD (both of self and bus-powered devices) |
Network
| COMPONENT | SPECIFICATION |
|---|---|
| Maximum Recording Rate | 384 Mbps |
| Maximum Bandwidth | Total 640 Mbps or less |
| Supported Protocol | IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SMTP, DNS, NTP, SNMP, RTP, RTSP, ICMP, ARP IPv6 : ICMPv6 |
| Upon Alarm or Warning | |
| No. of Simultaneous Users | 16 or less |
Other Functions
| COMPONENT | SPECIFICATION |
|---|---|
| Time Synchronization | NTP (Server/Client) |
| Summer Time | User definable (using menu setup) |
| Remote Monitoring on Smartphone/Tablet | 1000 cameras or less Allows the PC and mobile APP full access the multiple NU series / NX series NVRs. |
HDD
| COMPONENT | SPECIFICATION |
|---|---|
| HDD | Not installed, HDD canister: max. 9 slots (3.5″) |
| HDD Extension Unit | Max 5 of WJ-HXE410 or WJ-HXE400 can be attached. *In case using WJ-HXE400, please contact your dealer. |
| Maximum Capacity | Determined on “HDD compatilility chart” max.24TB supported. For Detail: https://i-pro.com/products_and_solutions/en/surveillance/learning-and-support/knowledge-base/compatibility-chart |
| RAID (Hardware RAID) | RAID1, RAID5, RAID6 (Hardware RAID) |
Viewer Software
| COMPONENT | SPECIFICATION |
|---|---|
| Playback Control | Play, Rev Play, Pause, FF, FR, Prev Record, Next Record, Prev Image, Next Image |
| Additional Functions | Alteration detection, Save as JPEG, Two times zoom, Print, Copy, Aspect ratio switching, fisheye correction, corridor display |
| Supported Language | English, Japanese |
Extension Software
| COMPONENT | SPECIFICATION |
|---|---|
| Camera Extension Kit | WJ-NXE52W (64ch→96ch→128ch), WJ-NXE53W (64ch→128ch) |
| Business Intelligence Kit | – |
| Secure Communication Kit | WJ-NXS01W, WJ-NXS04W, WJ-NXS16W, WJ-NXS32W |
General
| COMPONENT | SPECIFICATION |
|---|---|
| Safety/EMC Standard | DEMKO (IEC62368-1), CE/UKCA (EN55032/EN55035) |
| Power Source | AC100-240V (±10%), 50Hz/60Hz |
| Power Consumption | 145W 150VA |
| Ambient Operating Temperature | NVR: 0℃～45℃ (32℉～113℉) Mouse: 5℃～40℃ (41℉～104℉) |
| Ambient Operating Humidity | 5 % to 90 % (without condensation) |
| Maximum Operating Altitude | 2,000 m (6,562 feet) above sea level |
| Dimensions | 430 mm (W) x 132 mm (H) x 413 mm (D) {16-15/16 inches (W) x 5-3/16 inches (H) x 16-1/4 inches (D)} |
| Mass (Approx.) | 13 kg ｛28.7lbs｝* *If HDD is not mounted 20 kg ｛44.1lbs｝** **If 9 HDDs are mounted |
| Finish | Front Panel: Plastic, Powder Coating Top Cover: SECC, Powder Coating Rear Panel: SECC |
